Beamsplitter Penta Prisms
MgF2 Coated, Penta Prism Beamsplitter

MgF2 Coated, Penta Prism Beamsplitter

Beamsplitter Penta Prism by adding a wedge and with partial reflective coating on one of its leaning surfaces, Penta Prism can be used as Beamsplitter. Transmission/reflection (T/R) ratio of 50/50, or others for Beamsplitter Penta Prism is available upon request.

  • product origin:

    China

  • shipping port:

    Fuzhou China

  • lead time:

    4 working weeks

  • payment:

    T/T Payment, Western Union
Inquiry now
  • description

1.What is beamsplitter penta prism used for?



Beamsplitter Penta Prism by adding a wedge and with partial reflective coating on one of its leaning surfaces, Penta Prism can be used as Beamsplitter. Transmission/reflection (T/R) ratio of 50/50.



2.What kinds of materials can UNI Optics use to make right angle prism?



N-BK7, Grade A optical glass, Fused silica



3. What is UNI Optics standard manufacturing capability and top limit for beamsplitter penta prism?


 Beamsplitter Penta Prisms  Beamsplitter Penta Prisms


 Specification

Standard capability

Top limit

Dimension Tolerance

+/-0.2mm

+/-0.1mm

90° Deviation Tolerance

3’

3’’

Flatness

λ/2

λ/4

Surface Quality

60-40

40-20

Coating: Optional

input and output sides (S1 & S2)  AR coated

Beamsplitter Ratio T/R:  20/80±5 or 50/50±5

Reflectivity: R>90% per surface @630-680nm



4. What is the typical size?


Part No.

AxB(mm)

     L1=L2(mm)

UPBA001

   6.0x7.0

     9.90

UPBA002

   10.0x10.0

    14.14

UPBA003

   15.0x15.0

    21.21

UPBA004

   20.0x20.0

    28.28

UPBA005

   30.0x30.0

    42.42
