UN-TFA3528C-10MP
Taurus Series Compact FA Lens(10MP) Model UN-TFA3528C-10MP Focal length 35mm Aperture F2.8-16 Image Format 2.3″ Mount C Field Angle D x H x V (°) 2/3″ 1/2″ 1/3" D 18.39° 13.4° 10.1° H 14.8° 10.8° 8.10° V 11.1° 8.10° 6.10° Optical Distortion -0.172%y=5.5mm -0.077%y=4.5mm -0.045%y=4.0mm M. O. D. 0.2m~∞ Dimension Φ28*36.17mm Flange BFL 17.526mm Back Focal Length 13.63mm Operation Manual Iris Manual Focus Design Wavelength 420-1000nm Filter Thread M27xP0.5
View More
UN-TFA5020X-12MP
Taurus Series 4/3″ Format FA Lens(12MP) Model UN-TFA5020X-12MP Focal length 50mm Aperture F2.0-F22 Image Format 4/3″(23mm) Mount C Field Angle D x H x V (°) 4/3″ 1″ 1/2" D 26.0° 18.3° 9.2° H 21.0° 14.7° 7.3° V 15.8° 11.1° 5.6° Optical Distortion -0.13%@ y=11.5mm -0.05%@ y=8.0mm -0.01%@ y=4.0mm M. O. D. 0.3m Dimension Φ48*67mm Back Focal Length 20mm Design Wavelength 420~1000nm Operation Manual Iris Manual Focus Filter Thread M46×P0.75 Weight 219g Work Temperature -20℃～+60℃
View More
UN-TFA5028L-20MP
· High relative illumination and high contrast

· Low distortion and excellent corner brightness

· High resolution

· Compatible with 1'' and 1.1'' 20MP camera
View More
UN-TFA5020L-10MP
· High image contrast
· High brightness uniformity
· Suitable for 2.4u sensor, resolution upto 10MP
· Compact, lightweight and durable
View More
UN-GSWIR3514C
· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, upto F1.4
· Compact and lightweight design
View More
UN-ALS50J01
Product Features:

1. Compatible for 30mm Large Format Sensor

2. Large Aperture with F2.4

3.High Relative Illumination

4. Compatible for 2K-4K line scan camera

5. Ultra-low Distortion, low vertical axis chromatic aberration

6. Vibration-resistant and high stability.

Product information:Custom designs are available upon request.

Download the Datasheet of UN-ALS50J01
View More
